Kit, Drafting

Object Name: Kit, Drafting
Dimensions:
A. Case: 8" X 4 1/4" X 3/4"
B. Dividers: 6 1/8" L.
C.Screwdriver: 2 1/4" L.
D. Handle for ruling pen: 3 7/8" L.
E Head for ruling pen: 3" L.
F. Head for ruling pen: 1 3/8" L.
G. Head for lead ruling pen: 4" L.
H. Tin case of lead for ruling pens: 1 1/4" L. X 7/32" d.
I. Ruling pen: 4 7/8" L.
J. Ruling pen: 5 5/8" L.
K. Template: 3 3/4" X 2 3/8"
Medium: Steel
Catalog number: 82.2.36
DescriptionA. Case, black leather lined in blue velvet. Has slots for tools. Case has fold over ends. Sides have snaps. Post--Germany.

B. Dividers, Post--Germany. Metal bars w/adjustable points swing open on hinges.

C. Screwdriver. Plastic handle, metal blade.

D. Handle for ruling pen. Metal bar w/2 flat and two rounded sides. Adjusting screw.

E. Head for ruling pen. Metal, adjusting screw near points.

F. Head for ruling pen. Metal, adjusting screw.

G. Head for lead ruling pen. Metal w/2 separate points -- one lead. 3 adjusting screws.

H. Tin case of lead for ruling pens. Top is H1; bottom is H2. Contains five sticks of lead.

I. Ruling pen. Black handle. Adjusting screw on end of handle & near point of blade. Post--Germany.

J. Ruling pen. Red handle, adjusting screw near point of blade. Post -- USA.

K. Template. Thin metal plate with different shaped holes. K&E Co.
